Goldhorn P5 DSP Ultra

16Channel DSP/DSD Player

NOK79 990,00 inkl. mva.
På lager: 2 stk.
Ønskeliste
  • Produktinfo
  • Produktanmeldelser (0)

The P5 DSP Ultra from Goldhorn represents the apex of audio technology, offering an extraordinary listening experience. Outfitted with two ESS flagship DAC chips, ES9038Pro, and a potent triple-core DSP processor, it achieves a floating-point operation speed of up to 3.6 billion calculations per second. This enables the device to handle high-resolution audio formats like DFF, DSF, WAV, FLAC, and more, up to DSD 256, with a sampling rate of up to 192KHz, ensuring high fidelity playback.

Construction with high-end components marks the P5 DSP Ultra as a leader in sound quality. It features the exclusive Goldhorn GHA2000 chip, a three femtosecond clock system for precise timing, and durable electrolytic capacitors designed to operate reliably at high temperatures. The integrated DSP offers extensive control over the sound with a 30-band EQ, adjustable crossover frequencies, and individual channel time alignment. Connectivity is comprehensive, including multiple high-level inputs and outputs, USB DAC support, and wireless streaming via Bluetooth 5.0 and WiFi. Control is made easy with an IPS display, a digital remote, and app functionality. The P5 DSP Ultra is designed for those who demand the best in their audio equipment, offering advanced technology for top-tier sound quality.

 P5 DSP Ultra Technical Specs
DSP Chip ADAU1463 x 3PCS
DAC Chip 2 x ESS9083Pro w/ 7 DAC Filter Settings
ADC Chip 2 x AK5558VN
Opamp Proprietary
Capacitors High Temperature for High Reliability to 105°C electrolytics and WIMA film Caps
Music Formats HiRes: DFF / DSF / DSD Up to 256 Hi Res Uncompressed: WAV / FLAC / APE / AIFF / AIF Compressed: MP3 / AAC / OGG / WMA
Music Inputs USB Host x 3 1 x USB-DAC (to 192/32bit) Opt. and Coax (to 192/24bit BT 5.0 aptX HD/AAC/SBC
Control Inputs BT Wireless Remote Wi-Fi Mobile App Wired IPS Panel Controller included
PC Connection USB B
Processing Functions (See delay below) Crossover Frequency: 20Hz ~ 20kHz @ 1dB steps, Master Gain: 0 ~ 60dB, Channel gains: -20dB ~ +5dB Polarity: Phase Reversal 0 or 180, EQ filters Q 0.5 ~ 15 @ 0.1 steps, Input Mixer, Three Linking Functions: Volume Linking- Absolute or Relative, EQ Linking – Relative or Absolute, Crossover Linking – With EQ link on, Freq Link button will link crossovers
Delay 0 ~ 20ms / 0.005ms Steps
Output EQ EQ bands: All Channels 31 @ ± 15dB in 0.1dB Steps, Filter Functions: Peak / High Shelf / Low Shelf / 1st order All Pass/ 2nd Order All Pass
Crossover Butterworth & Bessel: 6, 12, 18, 24, 30, 36, 42, 48dB / Linkwitz: 12, 24, 36dB
XO Phase Rotation Variable Phase shift at HP and LP filters from 0° ~ 359°
Inputs 16 x Hi / 2 x RCA/Opt./Coax/USB-DAC
Input EQ EQ bands: All Channels 5 bands @ ± 15dB in 0.1dB Steps Filter Functions: Peak / High Shelf / Low Shelf / 1st order All Pass/ 2nd Order All Pass Input Delay: 0 ~ 10ms in 0.02 Steps
Frequency Resp: 10Hz ~ 80kHz
Operating Voltage 11v-16v
Input Sens (V) RCA
Input Sens (V) Hi
RCA Out Voltage 16 x 6V
RCA Out Specs THD+Noise 0.00018 S/N >125
Amp Outputs | THD+Noise 100dB N/A
Dimensions (mm) 303 x 231 x 50
Start-Stop ready Yes
EPS (Intelligent High-Level Input-Error Protection System) Yes
Finish Balck Anodized Aluminum
Auto Turn On via DC Offset or Signal Sensing Yes
Remote Turn on Output Yes
Clipping LED’s No
Built in Bluetooth aptX HD
Built In Wifi Yes
THD+Noise RCA 0.00018%
S/N ratio RCA >125dB
THD+Noise Amplifier N/A
S/N ratio Amplifier N/A
Fuse Rating 10A
Input impedance: No Impedance adaptor needed 6 Ohm High Level
Controller BT Wireless Player Remote, Optional Wired Panel controller w/IPS Display Screen, Wi-Fi Mobile App control
Input Mixer Yes
Presets 8
Software Interface PC 32bit Windows 7 and up
All Pass filters at input and output EQs Both 1st Order and 2nd Order
Navigation Mode w/ Input Priority Yes
Automatic Mode Switching Mixer Yes
Password Available Yes
Analog Noise Gate Yes
Variable Power Off Delay Yes
Seven DAC rolloff choices for ESS 9038 Yes
